Prysmian Flat Twin & Earth Cable 2 Core & Earth 7/0.67mm 2.5sq-mm 450/750V Plain Annealed Copper PVC/PVC White

Description

Flat Twin & Earth Cable, 2 Core & Earth, 2.5 mm, Plain Annealed Copper, 450/750 Volt, 7/0.67 mm Strands, 2 mm Nominal Diameter, 2.5 mm Earth Conductor, 12.4 mm x 5.5 mm Overall Diameter, 20 mm Bend Radius, 0.7 mm Insulation Thickness, Conductor Resistance: DC: 7.41 Ohm/km, V-90 PVC Insulation, 3V-90 PVC Sheath, Red Black Green/Yellow Cores, White Sheath, 90 deg C, AS/NZS 5000.2

Key Specifications

Brand	Generic
Product Type	Power Cable
SKU	CBL2.5TE-2
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	200
UNSPSC Class	26121600
UOM	MTR
Vendor Product	20201111
Voltage	450-750 Volt
Conductor Type	Plain Annealed Copper
Core Colours	Red Black Green Yellow
Sheath Colour	White
Bend Radius	20 mm
Conductor Resistance	DC: 7.41 Ohm/km
Insulation Material	V-90 PVC
Insulation Thickness	0.7 mm
Nominal Diameter	2 mm
Overall Diameter	12.4 mm x 5.5 mm
Sheath Material	3V-90 PVC
Standards	AS/NZS 5000.2
Stranding	7/0.67 mm
Temperature	90 deg C
